Pilous D System Bandsaws (Pilous D System Bandsaws)

Brand : Pilous

Price : 0,00 EURO(Vat included)

Stock Amount : 0

Note: The prices shown here are retail sales prices. SPECIAL DISCOUNT MAY APPLY FOR BULK PURCHASES . Additionally, discounted prices offered to dealers may differ.

Import duties, customs charges, and value-added taxes for products originating outside of Turkey are not included in the listed prices. This is applicable to customers purchasing from within Turkey.

The prices mentioned here do not include door-to-door delivery. Buyers purchasing from other countries are responsible for customs duties and any other taxes applicable under their local commercial laws.

For orders under 13,000 Euros, if the product value is below this, the total order value must either reach 13,000 Euros or a 150 Euro customs fee will be added to your final invoice value.

Ask For Offer

Add to Favorites

Add to My Wish List

Compare

Notify me when the price goes down

Notify me when it is in stock

Artır Azalt

Delivery Time 45 Days After order

Shipment Place Turkiye

Payment Terms % 30 T/T On Order Confirmation, % 70 T/T Before Shipment

Made In Czech Republic

Min. Order Qty.1 Pcs.

Warranty1 year

A massive, extremely stable and original modular system allows for variability in roller placement and very easy installation of the accessories - manual or digital measuring devices, metal sheet covers between individual rollers, material chute, additional rollers including plastic rollers, material container and the coolant tank.
Extreme stability and service life is guaranteed by the 3 mm thick galvanized metal sheets that cover all parts of the device.
The conveyors are manufactured with roller width 200, 300 or 400 mm. Individual modules are 2 and 3 m long and can be mutually connected.
To achieve maximum stability, the 2 m conveyor is equipped with one leg and the 3 m conveyor with two legs. The utmost legs are additionally secured with a pair of corner reinforcements.
There are necessary connecting and interconnecting pieces available that allow for installation to a whole range of machines.
The massive pull-out system allows for adjustable leg height ranging from 865 mm to 935 mm.

	roller width	number of legs	number of rollers	roller diameter	total length [mm]	load-carrying capacity [kg/1m]	max. number of rollers
D 200 / 2m	200	1	6	60	1980	300	17
D 300 / 2m	300	1	6	60	1980	300	17
D 400 / 2m	400	1	6	60	1980	300	17
D 200 / 3m	200	2	10	60	2980	300	27
D 300 / 3m	300	2	10	60	2980	300	27
D 400 / 3m	400	2	10	60	2980	300	27

DO – Manual measuring device

A simple and effective measuring of the required material length.
Can be installed on all types of D conveyors.
You can set the required length manually on an analogue (millimeter) scale with a simple arrestment.
Exceptionally stable system of movable slide stop is retractable in order to prevent gripping of the material and consequent damage to the saw band.

	measured length [mm]	total length [mm]
DO 200, 300, 400 / 2m	1700	1980
DO 200, 300, 400 / 3m	2700	2980
DO 200, 300, 400 / 4m	3700	3955
DO 200, 300, 400 / 5m	4700	4955
DO 200, 300, 400 / 6m	5700	5955

(includes the slide stop system and analogue scale of the appropriate length, not the conveyor itself)

DOD – Digital measuring device

A simple and effective measuring of the required material length.
Can be installed on all types of D conveyors.
You can set the required length manually on an analogue (millimeter) scale with a simple arrestment.
Exceptionally stable system of movable slide stop is retractable in order to prevent gripping of the material and consequent damage to the saw band.

	measured length [mm]	total length [mm]
DOD 200, 300, 400 / 2m	1700	1980
DOD 200, 300, 400 / 3m	2700	2980
DOD 200, 300, 400 / 4m	3700	3955
DOD 200, 300, 400 / 5m	4700	4955
DOD 200, 300, 400 / 6m	5700	5955

(includes the slide stop system with digital measuring device and a magnetic tape of an appropriate length, not the conveyor itself)

	DVO – additional steel rollers for increased carrying capacity Load-carrying capacity of the roller 100 kg. DVL – lightweight plastic rollers Prevent damage to the surface of the material. Load-carrying capacity of the roller 10 kg. DVS – heavy plastic rollers Prevent damage to the surface of the material. Load-carrying capacity of the roller 45 kg.
	DA1 – metal sheet cover between individual rollers Prevents short workpieces from falling through. Length 100 mm. (according to the layout of the rollers)
	DA2 – metal sheet cover between individual rollers Prevents short workpieces from falling through. Length 200 mm. (according to the layout of the rollers)
	DK – tiltable, detachable material chute Intended to be placed behind the cut when cutting short segments in series.
	DZ – material magazine for easier handling Width 100 mm, length 670 mm, carrying lenght 470 mm, load 2000 kg.
	DN – additional conveyor leg
	DX – additional corner reinforcement for detached conveyors
	DT – intermediate piece for connecting of the conveyors to the individual machines
