Ostas OPK-125 Rolls Hydraulic Profile Bending Machine (Ostas OPK-125)

Brand : Ostas

Price : 35.175,00 EURO

Stock Amount : 0

Delivery Time 45-60 Days After O.C.

Shipment Place Turkiye

Payment Terms % 50 T/T On O.C., % 50 T/T B.S.

Made In Turkiye

Min. Order Qty. 1 Pcs.

Warranty1 Year

Ask For Offer

Add to Favorites

Add to My Wish List

Compare

Notify me when the price goes down

Notify me when it is in stock

Artır Azalt

• Steel construction welded body
• 3 roller balls are driven by hydromotor and planetary reducers (Each ball is driven by 3 separate planetary reducers)
• Hardened rolls
• Hardened and ground products made of special high quality materials
• Movable control panel separate from the body
• 3-way hydraulic side supports
• Digital display 2 pieces
• Double speed operating system
• Horizontal working position only

• Automation with NC control
• Pulling apparatus
• Rolls for pipes and special profiles
• Stepless hydraulic speed adjustment system

Model	OPK-125
Engine Power (kw)	15
Roll Rolls (Ø mm)	390
Shaft/Shaft (Ø mm)	120
Working Speed (m/min)	2-7,5
Machine Size W X L	1700x2000x1950
Weight (kg)	4800

BENDING CAPACITIES
NO	Profile Type	OPK 125		Note
NO	Profile Type	Size	Min Dia.	Note
1		125X25 30x10	1200 500	Standard Rolls
2			1000 500	Standard Rolls
2		200x50 100x10	1000 500	Standard Rolls
3			750 500	Standard Rolls
3		65x65 20x20	750 500	Standard Rolls
4		Ø80 Ø20	900 500	Optional Rolls
5		Ø160X4 Ø140X3 Ø50x2	2800 1500 500	Optional Rolls
6		Ø5"X6,35 Ø3/4"x2,87	1500 500	Optional Rolls
7		120X40X4 30x20x3	1800 500	Optional Rolls
8		90x3 30x5	1800 500	Optional Rolls
9		120X120X12 40x40x4	1200 600	Optional Rolls
10		100X100X10 40x40x4	1200 600	Optional Rolls
11		100X11 30x4	800 500	Standard Rolls
12		100X11 30x4	1000 500	Standard Rolls
13		100X11 30x4	800 500	Optional Rolls
14		UPN 120 UPN 180 UPN 40	1000 800 500	Standard Rolls
15		UPN 120 UPN 180 UPN 40	1200 900 600	Standard Rolls
16		IPN 220 IPN 80	1000 500	Optional Rolls
17		HEB 120 HEB 140	1200 1200	Optional Rolls
18		UPN 120 UPN 100	10000 7500	Optional Rolls
19		IPN 160 IPN 140 IPN 100	5000 4000 2000	Optional Rolls
20		HEB 100 HEB 120	1600 4000	Optional Rolls
