Brand : Ostas
Stock Code (Ostas 4R OHS 3070X275)
Delivery Time 45-60 Days After O.C.
Shipment Place Turkiye
Payment Terms % 50 T/T On O.C., % 50 T/T B.S.
Made In Turkiye
Min. Order Qty. 1 Pcs.
Warranty1 Year
Stock Amount : 0

Note: The prices shown here are retail sales prices. SPECIAL DISCOUNT MAY APPLY FOR BULK PURCHASES . Additionally, discounted prices offered to dealers may differ.

Import duties, customs charges, and value-added taxes for products originating outside of Turkey are not included in the listed prices. This is applicable to customers purchasing from within Turkey.

The prices mentioned here do not include door-to-door delivery. Buyers purchasing from other countries are responsible for customs duties and any other taxes applicable under their local commercial laws.

For orders under 13,000 Euros, if the product value is below this, the total order value must either reach 13,000 Euros or a 150 Euro customs fee will be added to your final invoice value.

Item is out of stock.
Price : 42.771,00 EURO

4R OHS hydraulic bending machines are used in the bending process of medium and heavy platinum sheet metal, aluminum, or stainless materials, thanks to their welded strong steel body, hydraulic movement of the bottom and side rolls, and planetary gearbox that is connected to the main engine. 4R OHS roll bending machines, with their strong steel body and hydraulic movement through lower-lateralrolls, ore used forrolling sheet, aluminium or stainless materials and light or medium sheet via propulsion through planet redactor connected to the main motor.

  • Steel constructed machine body ST-52
  • Well-equipped shafts mode from certified steel with SAE1050 (CK-45) Hydraulic up and down movement system with bottom and laterals rolls
  • Hydraulic Drop-End for easy roll positioning
  • Hardened rolls
  • Conical bending device
  • Mobileelectrical controlpanel
  • Movement and parallelism adjustment of the rollers controlled from control panel
  • Three digitalreadouts for easy roll positioning
  • Hydraulic balancing system
  • Overload protection
  • Accordance with CE standards
  • Two - speed working system (0275 andabove)
  • Oil cooling system (0275 andabove)
  • Electro-hydraulic calibration
