Litz VB-1300B/BG Vertical Machining Center (VB-1300B/BG)

Brand : Litz

Stock Amount : 0

Est. Delivery Time60-75 Days After Order

Shipment Place Turkiye

Payment Terms% 30 T/T On Order Confirmation, % 70 T/T Before Shipment

Made InTaiwan

Min. Order Qty.1 Pcs.

Warranty1 Year

Machining Centers

Vertical Machining Centers

Spindle
Spindle speed：8000RPM (BG)	Standard
Spindle speed：10000RPM (B)	Standard
Spindle oil cooling system	Standard
Spindle dust-proof air-sealing system	Standard
Cooling System
Spindle external programmable air blow system	Standard
Programmable coolant nozzle	Standard
Splash ring(arm type only)	Standard
Coolant cooling system	Standard
Chip Removal System
Chip auger inside the machine	Standard
Chip conveyor	Standard
Chip cart	Standard
Coolant gun for machine cleaning	Standard
Air gun for machine cleaning	Standard
Wash down device	Standard
Fully-covered sheet metal	Standard
Oil/coolant separator
Automatic Tool Changer Mechanism (ATC)	Standard
ATC System
BT-50 tool specification	Standard
Arm type tool magazine 30T	Standard
3-Axes Transmission System
Counter weight central guide device	Standard
Controller
FANUC 0iMF	Standard
Electrical Parts
Work light	Standard
Alarm indicator	Standard
M30 automatic power off system	Standard
Heater exchanger for electrical cabinet	Standard

Spindle
Coolant through the spindle system (CTS)	Optional
Cooling System
Stop block for oil feed tool holder	Optional
Measurement System
Tool length measurement system	Upon Request
Workpiece measurement system	Upon Request
Oil/coolant separator
Disc type oil/coolant separator	Optional
ATC System
Arm type tool magazine 40T	Upon Request
3-Axes Transmission System
3-axes linear scale	Optional
Controller
Mitsubishi M80	Optional
Siemens 828D	Optional
Electrical Parts
Air-conditioner for electrical cabinet	Optional
Miscellaneous
4th Axis (rotating table)	Upon Request
Oil Mist Collector	Optional

Travels for 3-axes
X-axis Travel	mm	1300
Y-axis Travel	mm	610
Z-axis Travel	mm	600
Spindle nose to worktable surface	mm	125~725
Spindle center to Z rail surface	mm	660
Table Center to Z axis rail surface	mm	355~965
Table surface to floor	mm	988
Spindle
Spindle Speed	RPM
Automatic Tool Changing System
Number of Tools	T	30
Max. tool length	mm	305
Max. tool weight	kg	15
Tool changing method		ARM
Tool specification		BT-50
Worktable
Worktable area	mm	1500x600
Worktable max. load capacity	kg	1000
Working area	mm	1300x600
T-slot (No. x Width x Distance from the center)	mm	5x18x100
Rapid Speed
X-axis rapid speed	M/min	30
Y-axis rapid speed	M/min	30
Z-axis rapid speed	M/min	24
Controller
		FANUC 0i MF
Miscellaneous
Machine Weight	kg	10000
Coolant Tank Capacity	L	450
Power Consumption	KVA	25
Compressed air source	kg/cm²	6
