Litz TX-700 Compact Tapping Center (High Speed Model) (TX-700)

Brand : Litz

Stock Amount : 0

Est. Delivery Time60-75 Days After Order

Shipment Place Turkiye

Payment Terms% 30 T/T On Order Confirmation, % 70 T/T Before Shipment

Made InTaiwan

Min. Order Qty.1 Pcs.

Warranty1 Year

Spindle
Spindle Speed 12000RPM	Standard
Spindle Air Blow Device	Standard
Rigid Tapping	Standard
Controller
Mitsubishi M80	Standard
Cooling System
Coolant Cooling System	Standard
Spindle External Programmable Air Blow System	Standard
Chip Removal
Cutting Fluid System	Standard
Cleaning Water Gun	Standard
Cleaning Wind Gun	Standard
Full Enclosure Cover (Panel)	Standard
Slideway Protection Cover X / Y / Z	Standard
Lubrication System
Central Lubrication System	Standard
Automatic Lubricating Oil Lubrication	Standard
ATC Tool Changing
ATC Magazine Tool Number 21T	Standard
Tool Specifications BT-30	Standard
Automatic Tool Change System	Standard
Electrical
Front Door Safety Door Device	Standard
Worklight	Standard
Alarm Light	Standard
Heat Exchanger	Standard
M30 Automatic Power Off System	Standard
Miscellaneous
Base Bolts And Pads	Standard
Tool Box	Standard

Spindle
Spindle Speed 24000RPM	Optional
Spindle Oil Cooler	Optional
Coolant Through Spindle	Optional
Controller
Mitsubishi M830S	Optional
FANUC 0iMD	Optional
Chip Removal
Top Hood Protection Cover	Optional
Side Punching Device	Optional
Fixture Cleaning Device	Optional
Measuring System
Infrared Tool Breakage Detection	Optional
Workpiece Measurement System	Optional
Tool Length Measurement System	Optional
Oil/Coolant Separator
Disc Type Oil/Coolant Separator	Optional
Lubrication System
Manual Grease Lubrication	Optional
Automatic Grease Lubrication	Optional
ATC Tool Changing
ATC Magazine Tool Number 16T	Optional
Tool Specifications CAT Or Others	Optional
Servo Magazine	Optional
Electrical
Transformer Unit	Optional
Front LED Light	Optional
Miscellaneous
DDR Embedded Motor (4th Axis)	Optional
4th Axis (Rotating Table)	Optional
Tooling	Optional
CE Specifications	Optional
Raised Column 100 mm	Optional
Raised Column 200 mm	Optional
Automatic Door	Optional
Oil Mist Collector	Upon Request
Tailstock Support	Upon Request
Shock Absorption Foot Pads	Optional

Travel For 3-Axes
X-Axis Travel	mm	700
Y-Axis Travel	mm	400
Z-Axis Travel	mm	330
Spindle Nose To Workable Surface	mm	170 - 500
Spindle
Spindle Speed	rpm	12000
Automatic Tool Changing System
Number Of Tools	one of a pair	21
Max. Tool Diameter ( No Adjacent Knife )	mm	60 / 80
Max. Tool Length	mm	250
Max. Tool Weight	kg	3
Tool Changing Method		Disc Type
Tool Specifications		BT-30
Motor
Spindle Motor (Continuous/30min. Rated)	kw ( HP )	3.5 / 5.5
Motors On X/Y/Z-Axis	kw	1.5 / 1.5 / 2.2
Worktable
Worktable Area	mm	850 x 400
Worktable Max. Load Capacity	kg	250
T-Slot (Number X Width X Distance From The Center)	mm	3 x 14 x 125
Rapid Speed
X-Axis Rapid Speed	M/min	48
Y-Axis Rapid Speed	M/min	48
Z-Axis Rapid Speed	M/min	48
Cutting Feed Rate	mm/min	1 - 20000
Controller
Mitsubishi		M80
Miscellaneous
Machine Weight	kg	3500
Power Consumption	KVA	15
Coolant Tank Capacity	L	200
Compressed Air Source	kg/cm2	6
