Leadwell V-22iF/iR Machining Centre (V-22iF/iR)

Brand : Leadwell

Stock Amount : 0

Est. Delivery Time60-75 Days After Order

Shipment Place Turkiye

Payment Terms% 30 T/T On Order Confirmation, % 70 T/T Before Shipment

Made InTaiwan

Min. Order Qty.1 Pcs.

Warranty1 Year

Machining Centers

Machining Centre

High Rigidity:	RS232	Standard
*FEA Analysis	Full Enclosure Guarding	Standard
*High rigidity structure design	Work Light	Standard
*3 Axis ball screw prestressing	Alarm Light	Standard
High Reliability:	Heat Exchanger	Standard
*Roller type motion system	Rigid Tapping	Standard
*3 Axis absolute motor	Auto Counter For Workpiece	Standard
High Efficiency:	Chip Conveyor (Auger type) + 2 Chip Buckets	Standard / Not Available
*V-32A.V-42A.V-52A with high torque spindle motor	Remote MPG	Standard
*Rapid feed rate 48/48/36mm	Spindle Speed 8000 rpm	Standard
*Spindle speed 12,000rpm(optional)	FANUC Control	Standard
*Tool change time T to T 1.8sec	Tool Tip Air Blow System	Standard
*Tool change time C to C 4sec
High Flexibility:
*30 tools magazine available
*4/5 axis rotary table available
*Front/Rear Chip Disposal available

Siemens Control	Optional
Mitsubishi Control	Optional
Spindle Speed 10000 rpm (Steel Bearing)	Optional
Spindle Speed 12000 rpm (Ceramic Bearing)	Optional
Spindle Speed 15000 rpm (DDS)	Optional To Be Adviced
Spindle Speed 15000 rpm (DDS wşth CTS)	Optional To Be Adviced
Spindle Oil Chiller	Optional
C.T.S. Form A	Optional
Tool Overload Detection	Optional
Tool Management	Optional
Auto Tool Length Measurement TS-27	Optional
Automatic Workpiece Measurement OMP-60	Optional
Chip Conveyor Outside Machine & Chip Bucket	Optional
Chip Discosel At the Front	Optional
Chip Discposel At the Rear	Optional
Oil Skimmer	Optional
Coolant Gun	Optional
Air Conditioner	Optional
4th Axis Rotary Table Preparation	Optional
4Th Axis Rotary Table	Optional
Manual Chuck With Connecting Plate for Rotary Table	Optional
Manual Tailstock For Rotary Table	Optional
Power Disk for 4Axis Rotary Rable	Optional
Through Hole Drill Kit	Optional
DNC Link Software	Optional
Programmable Nozzle	Optional
Programmable Air Blow	Optional
CTS Preparation	Optional
Simple Filtrating System & 20bar /25u pump sys.	Optional
Simple Filtrating System & 40bar /25u pump sys.	Optional
Sub Tank	Optional
Extra Coolant Tank	Optional
Spindle Annular Coolant Jet (Arm Type ATC)	Optional
2 Speed Gear Box	Not Available
Arm Type ATC 30 Tools	Optional / To Be Adviced
Linear Scale	Optional / To Be Adviced
Surrounding Coolant System	Optional

ITEM		MODEL
		V-22İF/İR
A.T.C.	Type	ARM
CAPACITY	Unit
X Axis Travel	mm (in)	510(20.1)
Y Axis Travel	mm (in)	420(16.5)
Z Axis Travel	mm (in)	510(20.1)
Distance From Table Top to Spindle End	mm (in)	100-610(4-24)
Distance From Column Front to Spindle Center	mm (in)	460(18.1)
TABLE
Table Size (LxW)	mm (in)	600X400(23.6X15.7)
Max. Table Load Weight	kg	250
T-Slot Size	mm	18X125X3
SPINDLE
Spindle Speed	rpm	10000, 12000
Spindle Nose (Normal Size, No.)		7/24 Taper, No.40
Spindle Bearing Inner Diameter	mm (in)	60(2,36)
FEED RATE
Rapid Traverse X/Y/Z	m/min(ipm)	4/48/36(1890/1890/1417)
Max. Cutting Feed Rate	m/min(ipm)	10(394)
A.T.C.
Tool Storage Capacity	pcs.	24
Max. Tool Diameter (With Adjacent Tools)	mm (in)	80(3.15)
Max. Tool Length	mm (in)	250(9.8)
Tool Change Time T-T/C-C	sec	2.4/5
MOTORS
Spindle Motor (30 Min) FANUC	kw(hp)	11/(14.7)
X/Y/Z Axis Motor	kw(hp)	4/4/4(5.4/5.4/5.4)
MACHINE SIZE
Height Of Machine (H)	mm (in)	2370(93)
Floor Space (LxW)	mm (in)	2440x2117(96x83)FRONT/2130x2400(84x94)REAR
Total Machine Weight	kg	3455 FRONT/33820 REAR
Power Requirement	Kva	30
Controller	FANUC	Oİ-M
AVAILABLE CONTROLLER : SIEMENS/MITSUBISHI/HEIDENHAIN
