• Automatic Feeding Of Profiles
• Gluing "L" Shaped Sill
• Right-Left Milling
• Grooving
• Joint(juncture) Opening
• Chamfering
• Capacity: 300 - 500 Pieces Per Hour
K
8-25 mm
M
3-6 mm
W
65-100 mm
H
10-42 mm
Thickness of main workpiece
8-30 mm
Thickness of side workpiece
Width of main workpiece
65-125 mm
Width of side workpiece
10-45 mm
Working Speed
10-25 m/dak
Capacity of the glue pot
4 kg
Resistance Power of glue pot
3800 watt
Total Motor Power
16 kw
Output for Sawdust
4 pcs
Total Electric Power
18 kw
Air pressure
6 bar
Mains Voltage
380 V, 50-60 Hz
Current Intensity
78 A
Working Dimensions (L/W/H)
6500 x 1200 x 1400 mm
Shipping Dimensions (L/W/H)
4500 x 1200 x 1700 mm
Weight
1820 Kg
