• Direct-Gear Driven
• Wye-Delta Starters
• Air or Water Cooled
• Standard 1800 rpm ODP motors (TEFC motors optional)
• NEMA 4 Control Enclosure
• All filters are easily accessible.
• Servicing the separator does not require any piping removal.
• Quick access to all service items.
Slow speed, over-sized design ensures decades of dependability
• Larger airends, running at slower speeds, maximize efficiency and increase reliability.
• There are more Electra Saver and Electra Saver II compressors running in North America than any other rotary screw compressor.
AirSmart™ Controller is more than just a controller
• Maintenance and error handling information allows for quick system information to be conveyed to the user.
• Easy access to consumable part numbers when re-ordering is necessary.
A Serious Legend
The engineering ingenuity of Gardner Denver began in 1859. For over 150 years, our compressed air products have been a dependable resource for meeting the world’s most demanding and ever-changing industrial needs. A legend in its own right, the Electra Saver was founded on slow-speed, 1800 rpm design principles and has been providing decades of dependability.
Featuring super-sized bearings and up to 40% larger airends than the competition, Electra Saver compressors not only outperform competition, but outlast them.
Even with careful planning, most systems experience varying air demand. As a result, compressors operate below their full-load rated capacity at what is most commonly referred to as “partial load.” The horsepower consumed at partial load operation can be significant. Gardner Denver recognized this fact and developed a variable displacement technology designed to match compressor output to compressed air demand. The patented TurnValve™ was introduced over 30 years ago to maximize compressor efficiency. The TurnValve displaced inlet throttling technology which was the most efficient means of compressor capacity control and eliminated wide pressure f luctuations and massive storage requirements.
Basic Operating Principle
Air is drawn in through the fully opened inlet valve. Volumes of air are encapsulated between the male and female rotors and airend housing. The volumes are reduced through further rotation of the rotors to a fixed compression ratio and discharged out of the airend at operating pressure.
Design Features
The cylindrical TurnValve has a helix-shaped relief on its outside diameter which mates to a precisely machined bore within the body of the airend housing. The TurnValve is supported axially by oversized tapered roller bearings to permit rotation through a hydraulically operated rack and pinion arrangement. Openings, or windows, conjoin the compression chamber of the airend with the TurnValve bore where the circumference is sealed by tight clearances and lubricant to prevent air leakage during operation.
Full Load Operation
When full capacity is required, the TurnValve is positioned such that the windows are closed, resulting in maximum volume output of the airend.
Part Load Conditions
Upon detection of decreasing system air demand (rising pressure), the TurnValve is rotated into a position where the helix relief progressively opens the succession of windows until system air pressure has stabilized.
Trapped volumes of air are allowed to circulate back to the inlet without being compressed, resulting in only the required amount of air being compressed to meet system demands. The effective length of the rotor is shortened resulting in variable displacement operation allowing power use to drop, thus saving energy. The TurnValve provides the exact amount of compressed air to maintain system pressure for maximum efficiency—no more, no less. In fact, in the 60–100% of capacity range, where most systems operate, the TurnValve is more energy efficient than comparative units.
In the 60–100% of capacity range, where most systems operate, the TurnValve is more energy e cient than these comparative compressors.
Total System Protection
Since 1859, Gardner Denver has been supporting the compressed air industry with high quality, long-lasting compressor and air treatment solutions. Carrying on that legacy, our robust line of parts, lubricant and downstream accessories ensure your system stays healthy. Gardner Denver’s focus on total system protection not only includes OEM parts and fluid solutions, but a commitment to the longevity of your equipment through our industry leading warranty programs. Protect your investment.
Ensure your compressed air system remains a total package
Platinum Guard Service Offering
Platinum Guard is a preventative maintenance agreement serviced by Gardner Denver Authorized Distributors using genuine OEM parts and lubricants. Guard your investment with a service plan that keeps your compressor (and operations) running with few interruptions.
Platinum Trust Service Offering
The multi-year Platinum Trust service agreement offers peace of mind with extended coverage beyond the major components—the entire compressor package is included. Protect your equipment against unforeseen events with this service offering and guarantee consistent, reliable coverage from partners you trust.
