Angle Gauge
DATA-M LASER PROTRACTOR
Developed by Data M Engineering, it is a powerful solution for measuring bending angles in press brakes.
IRIS PLUS LASER PROTRACTOR
Automatic angle measurement and automatic correction of bending angle
KEBA DIGITAL ANGLE GAUGE
With KEBA angle measuring systems, complex bends can be performed extremely easily and with maximum accuracy.
Rear Support
PNEUMATIC REAR SUPPORTS
This is the latch group that is additionally mounted for easy bending in the machine and can also operate pneumatically apart from the backgauge.
Barcode Reader
BARCODE READER
Facilitates the operator's intensive and complex work processes and prevents errors.
Throat Depth
410 MM THROAT DEPTH
410 mm throat depth is standard.
510 MM AND ABOVE THROAT DEPTH
Special throat depths up to 1500 mm are offered for wider bending.
Crowning System
HYDRO-DYN CROWNING SYSTEM
Thanks to the CNC-controlled hydro-dynamic crowning system, it is possible to straighten with multiple hydraulic cylinders and a special measuring device (strain gauge), and thus achieve the ideal deflection balance by means of the force applied to the special lower beam.
HYDRAULIC CROWNING SYSTEM
Thanks to the CNC-controlled hydraulic crowning system, with multiple hydraulic cylinders, it is possible to achieve the ideal deflection balance by means of the force applied to the special lower beam.
HYDRO-MECHANICAL RIDGING
Thanks to the CNC-controlled hydro-mechanical crowning system, it is possible to achieve the ideal deflection balance with a hydraulic cylinder.
Bending Line
LASER BEND LINE - B-LIGHT 02
This is a system utilized for bending without the use of backgauge with the help of laser beam, and that allows the bending axis to be clearly visible.
LASER BENDING LINE - ROLLERI B-LIGHT 01
This is a system utilized for bending without the use of Backgauge with the help of laser beam, and that allows the bending axis to be clearly visible.
Ruler
RULER ON TOP BEAM
You can get precise results with Y1+Y2 axis synchronization with a tolerance of 0.01 provided by linear rulers.
Extraction System
SHEET EXTRACTION SYSTEM
This is the system that helps the bent products to be removed from the table of the press brake and transferred to the next stage.
Electric Panel Heating - Cooling
ELECTRIC PANEL HEATING AND COOLING SYSTEM
An optional electric panel with heating and cooling system, manufactured in accordance with CE standards is provided.
Tool Storage Cabinet
TOOL STORAGE CABINET
This is a cabinet manufactured by Ermaksan to protect the upper and lower dies used in our machine from external impact, and to keep them clean.
ROLLERI TOOL CABINET
This is a cabinet manufactured by Rolleri to protect the upper and lower dies in our machine from external impact, and to keep them clean.
Pendant Arm
STANDARD CONTROLLER ARM
This is the standard equipment in which the CNC controller, which is required for the machine to work, is mounted and allows the controller to move to the front or back of the machine when required.
ERGONOMIC CONTROLLER ARM
HEIGHT ADJUSTABLE CNC PENDANT ARM
The height-adjustable CNC pendant arm with shock absorber stands out with its modern design and functional features.
Led Bar Guiding System
LED BAR GUIDING SYSTEM
Shows the location of the bent pieces and bending stations with coloured LED bars.
WILA SMART TOOL LOCATOR
This system determines the order of use of the partial dies, which are mounted on the upper beam in full length, and attached to the top tool holder, by means of laser beam.
Robot Interface
ROBOT INTERFACE
Robotic automation solutions provide advantages in terms of efficiency, quality, speed, performance, cost, and safety.
Start-Stop
START-STOP
This is the optional system that stops the main motor when there is no upper beam movement in the machine within 2 minutes.
START-STOP + SOFT STARTER
This is the STAR - TRIANGLE motor speed change that we use as an option. Ensures safer and easier speed change for the motor.
Lubrication System
CENTRAL LUBRICATING SYSTEM
Automatic lubrication of the parts that require lubrication for extended lifetime of the machine by central lubrication system, without the need for an operator.
