Capacity
Max. swing over bed (mm)
φ630
Max. swing over slide (mm)
φ360
Max. turning dia. (4/6-station) (mm)
φ630/φ500
Distance between centers (mm)
1000
1500
2000
3000
Spindle
Spindle bore (mm)
φ105
Spindle nose
A1-11
Chuck dia. (mm)
φ315
Bore of spindle bearing (mm)
φ160 /φ140 /φ130
Spindle speed (r/min)
20-210 (L)
37-373 (M)
112-1120 (H)
Max. spindle torque (Nm)
1265
Carriage
Width of bed guideway (mm)
560
X/Z-axis motor and power (kW)
1.4/ 2.5
X/Z-axis rapid traverse (m/min)
6/7
X/Z-axis screw dia. and pitch (mm)
φ40×5/φ50×5
φ40×5/φ63×8
X/Z-axis travel (mm)
370/760
370/1310
370/1810
370/2810
Turret
Tool section (turning/boring mm)
32×32/Φ32
4/6
Width of tool block (mm)
200×200
Tailstock
Tailstock quill dia. (mm)
φ100
Tailstock quill taper (MT No.)
5
Max. travel of quill (mm)
250
Others
Power (kVA)
30
Main motor (kW)
11 kW frequency inverting motor
Dimension of machine (L×W×H cm)
355×200×185
400×200×185
450×200×185
560×200×185
Net weight (kg)
4600
5100
5600
6100
