SLIDING TABLE :
2800 mm
STANDART DIAMETER OF BLADE :
300 mm
DIAMETER OF SPINDLE :
30 mm
MAX. DEPTH OF CUT AT 90 DEGREE :
78 mm
MAX. DEPTH OF CUT AT 45 DEGREE :
55 mm
MAX. WIDTH OF CUT :
1300 mm
MAX. MOVEMENT OF ALUMINIUM TABLE
TABLE DIMENSIONS
950 x 600 mm
REAR ADDITIONAL TABLE DIMENSIONS
950 x 750 mm
SIDE ADDITIONAL TABLE DIMENSIONS :
800 x 500 mm
PROFILE CARRIAGE DIMENSIONS :
1530 x 650 mm
TILTING OF BLADE :
0°- 45° - AUTOMATİC
DUST VACUUMING CONNECTOR :
120 mm
MOTOR POWER :
5,5 hp (4 kW)
SPEED OF BLADE :
3700-5100 rpm
NET WEIGHT :
620 kg
45 - 90° AND UP - DOWN MOVEMENTS MOTOR POWER
0.09 Kw
45 - 90° AND UP - DOWN MOVEMENTS MOTOR SPEED
1500 rpm
SCORING UNIT
SPEED OF SAWBLADE :
7250 rpm
20 mm
DIAMETER OF SAWBLADE:
125 mm
1 hp (0,75) kW
LENGTH OF CUT :
