DISTANCE BETWEEN DRILL CENTERS :
32 mm X 640 mm
MAXIMUM BOTTOM DRILLING DEPTH :
50 mm
MAXIMUM FRONT DRILLING DEPTH :
SUPPORTING COMPONENTS :
PNEUMATIC
PRODUCTION YEAR :
2017
TOTAL ENGINE POWER :
15 kW
VOLTAGE :
380 - 400 V / 50 - 60 HZ
CURRENT :
30 AMPER
AIR PRESSURE :
6 - 8 bar
PNEUMATIC PRESS :
6 PIECE
DIMENSIONING :
INDICATOR
DIMENSIONS (length-height-width) :
4425 mm - 1720 mm -2120 mm
PIECE SIZE THAT CAN BE DRILLED AT X-AXIS (MIN-MAX) :
110 - 1100mm
PIECE SIZE THAT CAN BE DRILLED AT Y-AXIS (MIN-MAX) :
300 - 2800mm
WEIGHT (approx) :
2100 kg
